Servo dimensions | Standard |
Servo type | Digital |
Torque at 6.0V [kg∙cm] | 14 |
Torque at 7.4V [kg∙cm] | 17 |
Speed at 6.0V [s/60st.] | 0.055 |
Speed at 7.4V [s/60st.] | 0.045 |
Servo gears | Metal |
Ball bearings | 2× |
High-voltage | Yes |
Power supply [V] | 4.8 - 8.4 |
Length [mm] | 40.5 |
Width [mm] | 21 |
Height [mm] | 26.2 |
Weight [g] | 53 |
Intended for | On-road cars |
S.BUS | Yes |
S.BUS2 | Yes |
SR mode | Yes |
UR Mode | Yes |
Water resistance | No |
