Servo dimensions | Standard |
Servo type | Digital |
Thrust at 6.6V [kg∙cm] | 61 |
Speed at 6.6V [s/60st.] | 0.13 |
Thrust at 7.4V [kg∙cm] | 66 |
Speed at 7.4V [s/60st.] | 0.12 |
Servo gears | Metal |
Ball bearings | 2× |
High-voltage | Yes |
Power supply [V] | 4.8 - 8.4 |
Length [mm] | 40.5 |
Width [mm] | 21 |
Height [mm] | 39.4 |
Weight [g] | 82 |
Intended for | Aeroplanes |
S.BUS | Yes |
S.BUS2 | Yes |
SR mode | No |
Water resistance | No |
