AXI 5325/18 V2 brushless

This item is not available in you region (United States)

Supply voltage LiXX cells: 6 - 8 ; RPM/V [RPM/min/V]: 308 ; Nr. of turns: 18 ; Internal resistance [mOhm]: 32 ; No load current [A]: 1.6 ; max. effenciency [%]: 92 ; Max. efficiency current (η>85%) [A]: 18 - 65 ; Max. peak current (60 s) [A]: 81 ; Max. power [W]: 2440 ; Diameter [mm]: 63 ; Lenght [mm]: 64.2 ; Shaft diameter [mm]: 8 ; Weight [g]: 595 ; Nr. of poles: 14 ; Timming [°]: 15 - 25 ; ESC [A] : 90 - 120 ; Sailplane up to Weight [g]: 8000 ; Trainer up to Weight [g]: 6000 ; Acrobat up to Weight [g]: 5500 ; 3d up to Weight [g]: 5000

Powering LiXX cells	6 - 8
RPM/V [ot./min/V]	308
Turn count	18
Internal resistance [mOhm]	32
Open-circuit current [A]	1.6
Max. efficiency [%]	92
Max. efficiency current (η>85%) [A]	18 - 65
Max. peak current (60 s) [A]	81
Max. power [W]	2440
Diameter [mm]	63
Length [mm]	64.2
Shaft diameter [mm]	8
Weight [g]	595
Poles count	14
Timing [°]	15 - 25
ESC [A]	90 - 120
Weight of glider (up-to) [g]	8000
Weight of trainer (up-to) [g]	6000
Weight of acrobat (up-to) [g]	5500
Weight of 3D (up-to) [g]	5000
